Series: 15W7V, 25W1V
Product Series Features:
- High-shear ball nose
- Cutting edge length: 1.10" to 2.75"
EDP |
Part Number |
DC Cutting Dia. |
APMX Depth of Cut Max. |
LUX Usable Length Max. |
LPR Protruding Length |
OAL Overall Length |
ZNF Face Insert Count |
ZNP Peripheral Insert Count |
NOF Number of Flutes |
PRFRAD Profile Radius |
DCON Shank Dia. |
DXF File |
STEP Light File |
STEP Detailed File |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3007877 | 15W7V-1002880R01 | 1.000 | 1.100 | - | 2.87 | 5.12 | 2 | 2 | 1 | - | 1.000 | NA | |||
| 3010580 | 15W7V-1005780R01 | 1.000 | 1.100 | - | 5.75 | 8.00 | 2 | 2 | 1 | - | 1.000 | NA | |||
| 3010585 | 25W1V-2004082R01 | 2.000 | 2.750 | - | 4.00 | 7.25 | 4 | 10 | 1 | - | 2.000 | NA |
