Series: CDE
Product Series Features:
- 78° Parallelogram inserts with 2 indexes
Part Number |
Application |
RE Corner Radius |
BCH Corner Chamfer Length |
LE Cutting Edge Eff. Length |
INSL Insert Length |
W1 Insert Width |
S Thickness |
NOI Number of Indexes |
IH Insert Hand |
|
|---|---|---|---|---|---|---|---|---|---|---|
| CDE313L20 | Standard | 0.015 | - | - | 0.313 | 0.375 | 0.188 | 2 | Left | |
| CDE313L21 | Standard | 0.031 | - | - | 0.313 | 0.375 | 0.188 | 2 | Left | |
| CDE313L22 | Standard | 0.062 | - | - | 0.313 | 0.375 | 0.188 | 2 | Left | |
| CDE313L23 | Standard | 0.093 | - | - | 0.313 | 0.375 | 0.188 | 2 | Left | |
| CDE313L24 | Standard | 0.125 | - | - | 0.313 | 0.375 | 0.188 | 2 | Left | |
| CDE313L31 | Standard | 0.031 | - | - | 0.375 | 0.375 | 0.188 | 2 | Left | |
| CDE313L40 | Standard | 0.015 | - | - | 0.438 | 0.375 | 0.188 | 2 | Left | |
| CDE313L41 | Standard | 0.031 | - | - | 0.438 | 0.375 | 0.188 | 2 | Left | |
| CDE313L42 | Standard | 0.062 | - | - | 0.438 | 0.375 | 0.188 | 2 | Left | |
| CDE313L51 | Standard | 0.031 | - | - | 0.438 | 0.375 | 0.220 | 2 | Left | |
| CDE313L54 | Standard | 0.125 | - | - | 0.438 | 0.375 | 0.220 | 2 | Left | |
| CDE313R01 | Standard | - | 0.020 | - | 0.375 | 0.438 | 0.188 | 2 | Right | |
| CDE313R20 | Standard | 0.015 | - | - | 0.313 | 0.375 | 0.188 | 2 | Right | |
| CDE313R21 | Standard | 0.031 | - | - | 0.313 | 0.375 | 0.188 | 2 | Right | |
| CDE313R22 | Standard | 0.062 | - | - | 0.313 | 0.375 | 0.188 | 2 | Right | |
| CDE313R23 | Standard | 0.093 | - | - | 0.313 | 0.375 | 0.188 | 2 | Right | |
| CDE313R24 | Standard | 0.125 | - | - | 0.313 | 0.375 | 0.188 | 2 | Right | |
| CDE313R31 | Standard | 0.031 | - | - | 0.375 | 0.375 | 0.188 | 2 | Right | |
| CDE313R40 | Standard | 0.015 | - | - | 0.438 | 0.375 | 0.188 | 2 | Right | |
| CDE313R41 | Standard | 0.031 | - | - | 0.438 | 0.375 | 0.188 | 2 | Right | |
| CDE313R42 | Standard | 0.062 | - | - | 0.438 | 0.375 | 0.188 | 2 | Right | |
| CDE313R51 | Standard | 0.031 | - | - | 0.438 | 0.375 | 0.220 | 2 | Right | |
| CDE313R54 | Steel & General Purpose | 0.125 | - | - | 0.438 | 0.375 | 0.220 | 2 | Right | |
| CDE313R64 | Standard | 0.062 | - | - | 0.375 | 0.438 | 0.188 | 2 | Right | |
| CDE322L05 | Standard | 0.030 | - | - | 0.500 | 0.375 | 0.150 | 2 | Left | |
| CDE322R005 | Standard | 0.030 | - | - | 0.375 | 0.500 | 0.150 | 2 | Right | |
| CDE322R019 | Standard | 0.030 | - | - | 0.371 | 0.500 | 0.157 | 2 | Right | |
| CDE322R02 | Standard | 0.062 | - | - | 0.500 | 0.375 | 0.150 | 2 | Right | |
| CDE322R03 | Standard | 0.090 | - | - | 0.500 | 0.375 | 0.150 | 2 | Right | |
| CDE322R04 | Standard | 0.125 | - | - | 0.500 | 0.375 | 0.150 | 2 | Right | |
| CDE322R0C1 | Standard | 0.015 | - | - | 0.375 | 0.563 | 0.150 | 2 | Right | |
| CDE322R10 | Standard | - | 0.025 | - | 0.500 | 0.375 | 0.150 | 2 | Right | |
| CDE323L05 | Standard | 0.031 | - | - | 0.500 | 0.375 | 0.188 | 2 | Left | |
| CDE323L09 | Standard | 0.015 | - | - | 0.500 | 0.375 | 0.188 | 2 | Left | |
| CDE323L22 | Standard | 0.062 | - | - | 0.500 | 0.375 | 0.188 | 2 | Left | |
| CDE323L24 | Standard | 0.125 | - | - | 0.500 | 0.375 | 0.188 | 2 | Left | |
| CDE323L30 | Standard | 0.015 | - | - | 0.688 | 0.375 | 0.188 | 2 | Left | |
| CDE323L31 | Standard | 0.030 | - | - | 0.688 | 0.375 | 0.188 | 2 | Left | |
| CDE323L32 | Standard | 0.060 | - | - | 0.688 | 0.375 | 0.188 | 2 | Left | |
| CDE323L34 | Standard | 0.125 | - | - | 0.688 | 0.375 | 0.188 | 2 | Left | |
| CDE323R05 | Standard | 0.031 | - | - | 0.500 | 0.375 | 0.188 | 2 | Right | |
| CDE323R22 | Standard | 0.062 | - | - | 0.500 | 0.375 | 0.188 | 2 | Right | |
| CDE323R24 | Standard | 0.125 | - | - | 0.500 | 0.375 | 0.188 | 2 | Right | |
| CDE323R30 | Standard | 0.015 | - | - | 0.688 | 0.375 | 0.188 | 2 | Right | |
| CDE323R31 | Standard | 0.030 | - | - | 0.688 | 0.375 | 0.188 | 2 | Right | |
| CDE323R34 | Standard | 0.125 | - | - | 0.688 | 0.375 | 0.188 | 2 | Right | |
| CDE323RC4 | Standard | 0.030 | - | - | 0.500 | 0.375 | 0.173 | 2 | Right | |
| CDE324L25 | Standard | 0.188 | - | - | 0.500 | 0.375 | 0.250 | 2 | Left | |
| CDE324L26 | Standard | 0.230 | - | - | 0.500 | 0.375 | 0.250 | 2 | Left | |
| CDE324R22 | Standard | 0.060 | - | - | 0.500 | 0.375 | 0.250 | 2 | Right | |
| CDE324R25 | Standard | 0.188 | - | - | 0.500 | 0.375 | 0.250 | 2 | Right | |
| CDE324R26 | Standard | 0.230 | - | - | 0.500 | 0.375 | 0.250 | 2 | Right | |
| CDE333R01 | Standard | - | 0.020 | - | 0.688 | 0.435 | 0.188 | 2 | Right | |
| CDE333R80 | Standard | - | 0.020 | - | 0.688 | 0.430 | 0.188 | 2 | Right | |
| CDE334L09 | Standard | 0.030 | - | - | 0.750 | 0.375 | 0.250 | 2 | Left | |
| CDE334R04 | Standard | 0.230 | - | - | 0.750 | 0.375 | 0.250 | 2 | Right | |
| CDE334R09 | Standard | 0.030 | - | - | 0.750 | 0.375 | 0.250 | 2 | Right | |
| CDE424L32 | Standard | 0.060 | - | - | 0.688 | 0.563 | 0.250 | 2 | Left | |
| CDE424L35 | Standard | 0.187 | - | - | 0.688 | 0.563 | 0.250 | 2 | Left | |
| CDE424L36 | Standard | 0.230 | - | - | 0.688 | 0.563 | 0.250 | 2 | Left | |
| CDE424R01 | Standard | - | 0.020 | - | 0.500 | 0.563 | 0.250 | 2 | Right | |
| CDE424R22 | Standard | 0.060 | - | - | 0.500 | 0.563 | 0.250 | 2 | Right | |
| CDE424R24 | Standard | 0.125 | - | - | 0.500 | 0.563 | 0.250 | 2 | Right | |
| CDE424R35 | Standard | 0.187 | - | - | 0.688 | 0.563 | 0.250 | 2 | Right | |
| CDE424R36 | Standard | 0.230 | - | - | 0.688 | 0.563 | 0.250 | 2 | Right | |
| CDE424R80 | Standard | - | 0.020 | - | 0.500 | 0.559 | 0.250 | 2 | Right | |
| CDE434R01 | Standard | - | 0.020 | - | 0.898 | 0.562 | 0.250 | 2 | Right | |
| CDE434R82 | Standard | 0.125 | - | - | 0.898 | 0.563 | 0.250 | 2 | Right | |
| CDE444L02 | Standard | 0.125 | - | - | 1.000 | 0.500 | 0.250 | 2 | Left | |
| YDE334R09 | Multi-Purpose | 0.031 | - | - | 0.770 | 0.375 | 0.250 | 2 | Right |
