EDP: 2900622 Part: 5M5P-50R01 Series: 5M5P, 5M6P - Hi-Feed Face Mill
Representative image shown ⓘ
The image above is intended to represent the product series for illustrative purposes only. The actual product may vary.
View STEP
Available : 4
Product Series Features:
- Ø2.000-5.000”
- 13 mm insert with 4 indexes
- .088" (2.2 mm) Max. depth of cut
- 12° Hi-feed rougher
- Seven different insert edge preparations provide application flexibility
- Extremely free cutting!
- Excellent hi-feed performance & economy!
Notes:
- Refer to the product bulletin for detailed programming information. Note, when using inserts SDES1305MPR, SDES1305MPR-001 or SDES1305MPR-MR the nominal diameter is reduced .030 inch.
- Insert screw tightening torque: 30-35 in*lb.
| EDP | Part Number | ISO Number | Description | Additional Info | DXF File | STEP Light File | STEP Detailed File | |
|---|---|---|---|---|---|---|---|---|
| 7019041 | SM40-100-R0 | SM40-100-R0 | Screw, M4 × 0.7 × 10 mm, T15 Torx drive | n/a | n/a | n/a | ||
| 7002894 | SD-12-82 | SD12-82 | SHCS, 3/4-16 × 1.50", 5/8" Hex Drive | For use with 1-1/2" Pilot | n/a | n/a | n/a | |
| 7019679 | DS-A00T | DS-A00T | Magnetic Combination Straight & T-Style Handle with (2) 6 mm Hex Drive slots (1) Bit Holding Slot | n/a | n/a | n/a | ||
| 7002096 | DS-T156B | BLD T15/S7 | T15 Torx; 90 mm OAL; 6 mm Hex drive | n/a | n/a | |||
| 7031381 | SD-10-99 | SD10-99 | SHCS, 5/8-18 × 1.25" 1/2" Hex Drive, with (2) Coolant Grooves | Coolant Bolt - Optional Accessory Item; Sold separately | n/a | n/a | n/a | |
| 2920530 | DS-A00-.25-T | DS-A00-.25-T | Driver Handle for use with multi-component Qwik Torque system Preset Torque Adapters over 2.0Nm | Optional Accessory Item; Sold Separately | n/a | n/a | n/a | |
| 7000078 | DS-T15B | DS-0003 | T15 Torx Bit; 1.00" OAL; 1/4" Hex drive | Optional Accessory Item; Sold Separately | n/a | n/a | n/a | |
| 2920528 | DT-35-.25 | DT-35-.25 | Torque Adapter Unit preset to 35 in lb (4.0 N·m) for use with the multi-component Qwik Torque system | Optional Accessory item; Sold Separately | n/a | n/a | n/a |
PDF File
Open PDF with page(s) from Tooling Promo.
The PDF above is for this product.
Open a PDF of the entire 2026 Q4 Promo (4.1 MB).
Flip-Book
Open the 2026 Q4 Promo Flip-Book.
