Premium 4-Flute Coolant-Thru Solid Carbide 90° End Mills – Ideal for Various Machining Operations in Stainless Steel
Features and Benefits
- Outstanding performance in channel and shoulder applications
- Unique geometry with variable pitch and variable helix disrupts vibrations
- 2xD depth-of-cut (APMX)
- Up to 4xD usable length (LUX) provides a deep reach capability
- Coolant-thru (.250" and larger) for excellent chip control and reduced heat
- Comprehensive range of diameters, radii, and lengths... 138 unique tools in stock
• Series P4M1V: .125–.1875" diameter
• Series P4M2V: .250–.750" diameter
w/thru coolant - cylindrical and
Weldon shanks are in stock
Product Ranges & Details
Cutter Series
P4M1V-_C: Cylindrical shank
P4M2V-_C: Cylindrical shank with coolant thru
P4M2V-_W: Weldon flat shank with coolant thru
Geometry
4-flute, coolant thru (Ø.250" and larger), variable pitch, variable helix
Diameter Range
.125–.750"
Depth of Cut
2xD APMX and up to 4xD LUX
Grade
IN2205 (multi-layer PVD AlTiSiN)
Lead Angle
90°
Corner Radii
Sharp, .008", .015", .030", .060", .090", .125"
Materials:
Stainless Steel
